Earthquake Resistance Test
Simulate actual/artificial seismic vibrations and offer necessary data for products that require aseismic capacity
Earthquake waves for earthquake-resistance tests
We can perfectly simulate the seismic waves of the Great East Japan Earthquake, which is difficult for other companies, as well as both displacement and acceleration.
- Great East Japan: 2011
- Hanshin-Awaji: 1995
- Niigata-Chuetsu: 2004
- El Centro: 1940
- Tuft: 1952
- Off-Kushiro: 1993, etc.
Artificial earthquake waves for earthquake-resistance tests
|Earthquake Waves||Applicable for|
|NTT Artificial Earthquake Waves Issue December 1998||Standard earthquake-resistance tests for communications equipment to be stowed in the NTT buildings|
|NEBS (GR-63-CORE zone 4) Issue October 1, 1995||Earthquake-resistance tests for networking equipment|
|EN300019-2-3 Chapter4.2||European Telecommunication Standards earthquake-resistant designs for indoors|
|EN300019-2-4 Chapter4.2||European Telecommunication Standards earthquake-resistant designs for outdoors|
|IEC61587-2||Earthquake-resistance tests for racks, etc.|
For a manufacturer of electrical equipment, we conducted a performance test on the packing and stowing method of electrical equipment by simulating vibration during transportation.
Please see the video at the right side: Examples of the earthquake-resistance tests simulating Great East Japan, Hanshin-Awaji, and Niigata-Chuetsu.
JPY2,000,000/day for the 1st day and JPY1,500,000/day for the 2nd day and any subsequent days.
|(1) Number of acceleration
|If the number exceeds 39 channels, more accelerations sensors can be rented:
JPY15,000/channel/week. Calibration certificates for traceability can be arranged for JPY10,000/channel.
|(2) Strain measurement||We will be able to prepare strain gauges on actual expense.|
|(3) Report||1 set (in Japanese)
Reports in English are available at an additional JPY100,000.
|(4) Work contents||Performance of tests, measurements, data analysis, and a report are included in the basic price.
Bring-in, installation, clean-up, and removal of specimen should be organized by the customers’ responsibility. We are able to support customers for the above operation, including the handling of an overhead traveling crane.
- Overtime testing: JPY 250,000/hour
Overtime work: JPY 150,000/hour”
- Acceptance and/or setting in the afternoon before the test date: additional JPY500,000
Dismounting and/or removal in the morning after the test date: additional JPY500,000
If a full day is needed for the above: JPY1,000,000/day
- Displacement measurement: JPY150,000/point
- If needed, a forklift can be rented.
- If another electric power source is needed, an electric generator can be rented.
If you need 3-phase 200V during the vibration test, please ask us in advance.
- Video recording, DVD burning as tetrameric view:
JPY100,000/day for the 1st day and JPY50,000/day for the 2nd day and any subsequent days.
- Seismic-intensity meter: JPY50,000/day
If you do not have an order form from your company, please use our order form.
After receipt of a firm order, we will officially fix the test date.
If you would like to cancel the test or change the date after the test date has been fixed, we will charge a cancellation fee as shown in the following percentages of the total amount of our quotation.
- For cancellations two months to one month prior to the fixed test date: 50%
- For cancellations one month or less prior to the fixed test date: 100%
After receipt of our invoice, payment in cash must be made by the end of the next month.
Half the amount of the test fee might be required as advance payment for first-time customers.
For additional information about this service/product, please contact us by our inquiry form.
